3 Phase UPS | 15KVA/15KW | 380V/400V/415V | Battery Voltage: 360Vdc (Settable 336VDC/348VDC/372VDC/384VDC)
Prostar ET15K 3 phase double conversion online data centre ups 15kva 15kw is a high-performance digital UPS using the DSP control technology. The online UPS 15KVA is connected between the mains and critical loads to supply high-quality power to the loads.
The 3-Phase 380/400/415V 15kVA 15kW On-Line Double-Conversion UPS with IGBT technology provides battery backup and AC power protection against power disturbances. It’s recommended for critical IT or corporate infrastructure, telecom, LAN/WAN, security and emergency, financial and light industrial applications.
Prostar ET-PLUS series design allows continuous operation at any supported voltage at either 50 or 60 Hz. Zero transfer time to battery mode ensures no disruption to the attached loads. Automatic and Manual Bypass keeps connected equipment powered even during overloads and UPS maintenance.
1. Total cost of Ownership
1.1 Wide input voltage range and frequency range
Designed for harsh electrical environments to save battery life, and suitable for fuel generators or other power generation equipment.
1.2 ECO mode
Operating mode that ensures ultra-high efficiency while charging the batteries, conditioning the load power factor, and ensuring a Class 1 output voltage regulation.
1.3 Excellent footprint
Small UPS footprint provides maximum usage of valuable electrical room floorspace.
1.4 High efficiency
High efficiency rates that remain stable even at lower operating power levels.
2. Convenience
2.1 Bottom cable entry
Allows cabling from the bottom without the need of additional cabinets providing footprint savings and flexibility to the installation.
3. Availability
3.1 Most advanced and high frequency DSP technology
The high-performance DSP provides UPS more accurate measurements of output voltage and currents, also Fast response to overload and over-voltage conditions.
| PRODUCT NAME | 1KVA High Frequency Online UPS Built-in Battery |
| Model | PET1101B |
| Power Capacity | 1KVA/1KW |
| Battery Voltage | 24VDC |
| Power Factor | 1.0 |
| Dimension(DxWxH mm) | 385x143x222 |
| Weight(Kgs) | 8 |
| INPUT | |
| Input Format | L+N+PE |
| Rated Voltage | 208VAC/220VAC/230VAC/240VAC |
| Voltage Range | 110V-300VAC |
| Frequency Range | 50/60±6Hz(Default), ±10Hz(Settable) |
| Power Factor | ≥0.99 |
| Harmonic Distortion (THDi) | ≤3% THD(LinearLoad); ≤5%THD(Non-linearLoad) |
| OUTPUT | |
| Output Format | L+N+PE |
| Rated Voltage | 208VAC/220VAC/230VAC/240VAC |
| AC Voltage Regulation | ± 1% |
| Frequency Range | AC Mode:same as AC, Battery Mode:50/60Hz±1% |
| Harmonic Distortion (THDi) | ≤1% THD(LinearLoad); ≤3%THD(Non-linearLoad) |
| Power Factor | 1.0 |
| Overload Capacity | AC Mode: 30min@102%~110%load, 10min@110%~130% load, 30s@130%~150%load, 200ms@>150% load
Battery Mode: 1min@102%~110%load, 10s@110%~130%load, 3s@130%~150%load, 200ms@>150% load |
| WaveForm | Pure Sine Wave |
| TRANSFER TIME | |
| AC Mode to Battery Mode | 0ms |
| Inverter to Bypass | 4ms |
| EFFICIENCY | |
| AC Mode | 94.5%@220VAC |
| Battery Mode | 87.5% |
| BATTERY | |
| Battery Type | Depending on applications |
| Battery Numbers | 12V7Ah ×2 |
| Charging Current | 1A(Default), 1-4A(Adjustable) |
| Charging Mode | Two-stage/Three-stage charging |
| DISPLAY | |
| LCD Display | Working mode/load/input/output |
| ENVIRONMENT | |
| Operation Temperature | 0~40℃ |
| Storage Temperature | -15~60℃ ( Battery: 0~40℃ ) |
| Relative Humidity | 20%~95% (No condensation) |
| Altitude | ≤1000m |
| Noise | < 45dB@1 Meter |
| MANAGEMENT | |
| RS232/USB | Windwos2000/2003/XP/Vista/2008/7/8/10,Linux and MAC |
| Optional SNMP | Power management from SNMP manager and web browser |
